Table B-6 Model 2710m
Specifications:
Display Type: TFT LCD active matrix
Viewable Image Size: 68.58 cm (27 in.) diagonal
Tilt –5° to +25°
Maximum Weight (unpacked): 9.6 Kg (21.2 lb)
Dimensions (h x w x d): 469 x 671 x 214 mm (18.5 x 26.4 x 8.4 in.)
Maximum Graphics Resolution: 1920 x 1080 @ 60 Hz analog mode
Optimum Graphics Resolution: 1920 x 1080 @ 60 Hz analog mode
Text Mode: 720 x 400
Dot Pitch: 0.265 x 0.265 mm
Horizontal Frequency (analog mode): 24 to 94 kHz
Vertical Frequency (analog mode): 48 to 76 Hz
Environmental Requirements
Temperature (independent of altitude)
Operating Temperature: 5° to 35° C (41° to 95° F)
Non-Operating Humidity: –20° to 60° C (–4° to 140° F)
Relative Humidity (non-condensing):
Operating Humidity: 20% to 80%
Non-Operating Humidity: 5% to 95%
Power Source: 100–240 V AC (ca), 50/60 Hz
Power Consumption: 120 watts (W) maximum
Sleep Power Consumption: <2 watts (W) typical
Preset Video Modes
The monitor automatically recognizes many preset video input modes that will appear properly sized
and centered on the screen.
Table B-7 Factory Preset Video Input Modes, 1910m
Preset Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz)
1 640 x 480 31.47 59.94
2 720 x 400 31.47 70.09
3 800 x 600 37.88 60.32
4 1280 x 720 45.00 60.00
5 1024 x 768 48.36 60.00
6 1280 x 960 60.00 60.00
Preset Video Modes 35
