Service door
Description Spare part number
For use in computers with 39.6-cm (15.6-in) displays 605785-001
For use in computers with 35.6-cm (14-in) and 33.8-cm (13.3-in) displays 605784-001
Before removing the service door follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 51).
Remove the service door on a 39.6-cm (15.6-in) computer:
1.
Loosen the four Phillips PM2.0×3.0 captive screws (1) that secure the service door to the
computer.
2. Slide the service door (2) away from the computer.
Remove the service door on a 35.6-cm (14-in) or 33.8-cm (13.3-in) computer:
1.
Loosen the two Phillips PM2.0×3.0 captive screws (1) that secure the service door to the
computer.
52 Chapter 4 Removal and replacement procedures
