3. Remove the hall sensor board (3).
Reverse this procedure to install the hall sensor board.
Display assembly
NOTE: The display assembly is spared at the subcomponent level only. For more display assembly
spare part information, see the individual removal subsections.
Before removing the display assembly, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the keyboard/top cover (see
Keyboard/top cover on page 23).
5. Disconnect the battery cable from the system board (see
Speakers on page 26).
40 Chapter 4 Removal and replacement procedures preliminary requirements
