HP COMPAQ 6510B User Manual

System board
Description Spare part number
For use with HP Compaq 6515b computer models with WWAN capability (includes WWAN module
slot)
443896-001
For use with HP Compaq 6515b computer models without WWAN capability (does not include
WWAN module slot)
443898-001
For use with HP Compaq 6510b computer models with WWAN capability (includes WWAN module
slot)
446905-001
For use with HP Compaq 6510b computer models without WWAN capability (does not include
WWAN module slot)
446904-001
Before removing the system board, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 46).
5. Remove the following components:
a. Hard drive (see
Hard drive on page 50)
b. Memory/WLAN module compartment cover (see
Expansion memory module on page 54)
c. Optical drive (see
Optical drive on page 60)
d. Keyboard (see
Keyboard on page 62)
e. Switch cover (see
Switch cover on page 68)
f. Fan (see
Fan on page 69)
g. Heat sink (see
Heat sink on page 71)
h. Display assembly (see
Display assembly on page 75)
i. Top cover (see
Top cover on page 79)
When replacing the system board, be sure that the following components are removed from the defective
system board and installed on the replacement system board:
●
SIM (see
SIM on page 47)
●
Memory modules (see
Expansion memory module on page 54) and Internal memory module
on page 65)
●
WLAN module (see
WLAN module on page 56)
●
RTC battery (see
RTC battery on page 66)
86 Chapter 4 Removal and replacement procedures
