4 Removal and replacement procedures
Preliminary replacement requirements
Tools required
You will need the following tools to complete the removal and replacement procedures:
●
Flat-bladed screwdriver
●
Magnetic screwdriver
●
Phillips P0 and P1 screwdrivers
●
Torx T8 screwdriver
●
5.0-mm (3/16-inch) nut driver
Service considerations
The following sections include some of the considerations that you must keep in mind during
disassembly and assembly procedures.
NOTE: As you remove each subassembly from the computer, place the subassembly (and all
accompanying screws) away from the work area to prevent damage.
Plastic parts
Using excessive force during disassembly and reassembly can damage plastic parts. Use care when
handling the plastic parts. Apply pressure only at the points designated in the maintenance instructions.
38 Chapter 4 Removal and replacement procedures

HP Compaq 6530b Specifications

General

HDD speed	7200 RPM
HDD interface	-
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	160 GB
Number of HDDs installed	1
Bus type	FSB
Stepping	R0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo P8000 Series
Processor socket	Socket 479
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.53 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Motherboard southbridge	Intel ICH9M
Processor front side bus	1066 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	25 W
Processor core voltage (AC)	1.00 - 1.250 V
CPU multiplier (bus/core ratio)	9.5
Number of Processing Die Transistors	410 M
Operating system installed	Windows Vista Business
Operating system architecture	32-bit
Display diagonal	14.1 \
Display resolution	- pixels
Motherboard chipset	Intel GE45 Express
Memory slots	2x SO-DIMM
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 2 GB
Type	PC
Power supply type	AC/DC
Wireless technology	Wi-Fi
Compatible operating systems	Windows Vista
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Audio system	HD
Pointing device	Touchpad + Scroll zone
Bluetooth version	2.0+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
TV-out type	S-Video
Charging port type	DC-in jack
USB 2.0 ports quantity	4
CardBus PCMCIA slots quantity	0
Cable lock slot type	Kensington
AC adapter power	55 W
Number of battery cells	6
Product color	Black
Country of origin	China
Discrete graphics card model	Intel® GMA 4500MHD
Processor code	SLGFE
Processor ARK ID	37006
Processor package size	35 x 35 mm

Weight and Dimensions

Depth	242.8 mm
Width	334.8 mm
Weight	2410 g
Height (front)	32.6 mm
