Graphics/Video API
Support
Microsoft DirectX® 10, OpenGL® 1.5 (OpenGL® 2.0 available in a driver update)
Resolutions Supported
Maximum Refresh Rate (Hz)
Resolution Analog Connection Digital Connection
640x480 85 60
800x600 85 60
1024x768 85 60
1280x720 85 60
1280x1024 85 60
1440x900 75 60
1600x1200 85 60
1680x1050 75 60
1920x1080 85 60-R
1920x1200 85 60-R
1920x1440 85 N/A
2048x1536 75 N/A
2560x1600 N/A 60*
* Only supported when using a DisplayPort connection
Note:
Other resolutions may be available but are not recommended as they may not have been tested and
qualified by HP
Note:
60-R denotes reduced blanking timings are used on single-link DVI connections and may be used with other
digital connections
NVIDIA Quadro NVS 290 Graphics Card
Bus Type PCI Express x16; low profile PCI Express x1, low profile
Memory 256 MB 400MHz DDR2 SDRAM unified frame buffer, Z-buffer and Texture storage
Connector Single high-density DMS-59 Flex Connector
Dimensions Low-profile, 2.586 x 6.6 in (6.57 x 16.76 cm)
Multi-Monitor support Dual monitor support
RAMDAC Integrated dual 400MHz
Maximum Pixel Clock 350-MHz
Overlay planes One 16-bit video overlay plane One 1-bit video overlay plan
High Definition Video Processor
(HDVP)
Full screen, full frame video playback of HDTV and DVD content
DVD ready motion compensation for MPEG-2
Independent hardware color controls for video overlay
Hardware color space conversion (YUV 4:2:2 and 4:2:0)
IDCT motion compensation
5-tap horizontal by 3-tap vertical filtering
8:1 up/down scaling
Specification Description
QuickSpecs
HP Compaq 8100 Elite Series
Technical Specifications - Graphics
DA - 13524 Worldwide — Version 27 — September 30, 2011 Page 33
