HP Compaq d220 MT Hardware Reference Guide

1–12 Hardware Reference Guide
Hardware Upgrades
Removing a 5.25” Drive
1. Turn off the computer properly through the operating system and
turn off any external devices.
2. Disconnect the power cord from the power outlet and the
computer, and disconnect any external devices.
3. Remove both the right and left access panels.
4. Remove the front bezel.
5. Disconnect the power, data, and audio cables, as necessary, from
the back of the drive.
✎
In some cases it may be easier to slide the drive part way out of the
drive bay before removing the cables.
6. Remove the four screws, two from each side, that secure the drive
in the drive cage 1.
7. Slide the drive out of the drive cage, as shown in the illustration
below 2.
Removing a 5.25” Drive

HP Compaq d220 MT Specifications

General

Graphics	Integrated Intel Extreme Graphics 2
Operating System	Windows XP Professional
Form Factor	Microtower
Memory Type	DDR SDRAM
Maximum Memory	2 GB
Expansion Slots	3 PCI, 1 AGP
Audio	Integrated AC'97 audio
Network	Integrated 10/100 Ethernet
Power Supply	250W
Processor	Intel Celeron, Intel Pentium 4
RAM	Up to 2GB DDR SDRAM
Storage	40 GB or 80 GB Hard Disk Drive
Hard Drive Interface	ATA/100
Optical Drive	CD-ROM or DVD-ROM
Ports (Front)	2 USB 2.0, Microphone
Ports (Rear)	4 USB 2.0, Serial, Parallel, VGA
