Hardware Reference Guide 1–13
Hardware Upgrades
To install a drive, reverse the removal procedure.
✎
If you are installing a 5.25” drive for the first time into bay 2 you must
first remove the drive from bay 1 and then knock or pry out the metal
shield that covers the front of bay 2.
Å
WARNING: There may be sharp edges on the inside of the bay opening
after the shield has been removed.
Removing a Diskette Drive
1. Turn off the computer properly through the operating system and
turn off any external devices.
2. Disconnect the power cord from the power outlet and the
computer, and disconnect any external devices.
3. Remove both the right and left access panels.
4. Remove the front bezel.
5. Disconnect the power, and data cables from the back of the drive.
