ATI Radeon X1300 (256MB
SH) PCIe Graphics Card
(256 MB)
Bus type PCI Express (x16 lanes)
Maximum vertical refresh
rate
85 Hz
Display support Integrated 400 MHz RAMDAC
Display max resolution 2048 x 1536
Board display options DVI-I + TV
DVI-I supports analog CRT or flat panel or digital flat panel (using DVI-A, DVI-D
or DVI-I connector)
DVI-I supports analog CRT or flat panel (with VGA connector and DVI-I to VGA
dongle)
TV connector is a 4-pin mini-DIN S-video connector
Board configuration Specification Description
Graphics Chip RV515
Core clock 450 MHz
Memory clock 250 MHz
Frame buffer 256 MB DDR2
Languages supported 24 languages: English, Arabic, Chinese Simplified, Chinese Traditional,
Czechoslovakian, Danish, Dutch, Finnish, French, German, Greek, Hebrew,
Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian,
Spanish, Swedish, Thai, Turkish
Core power 25 W (Max board power)
Option kit contents ATI RADEON X1300 PCIe graphics card with full height bracket attached
Low profile bracket
DVI-to-VGA Adapter
Software CD with graphics drivers
Warranty documentation
Compliance standards EMC Emissions:
a) FCC Part 15, Subpart B – Unintentional Radiators, Class B Computing
Devices for Home & Office Use
b) CISPR22: 1997/EN 55022:1998 – Class B – Limits and methods of
measurement of radio disturbance characteristics of Information Technology
Equipment
c) Canadian Standard ICES-003 is equivalent to CISPR22
EMC Immunity:
CISPR 24:1997/EN 55024:1998 – Information Technology Equipment –
Immunity Characteristics – Limits and Methods of Measurement.
Safety:
UL 60950 (USA) & EN 60950 (EU): Safety of Information Technology
Equipment, Including Electrical Business Equipment. All boards meet UL PCB
flammability requirements.
QuickSpecs
HP Compaq dx2300 Microtower Business PC
Technical Specifications - Graphics
DA - 12668 North America — Version 17 — May 21, 2008 Page 23

HP Compaq dx2300 Specifications

General

Processor cache	1 MB
Processor cores	2
Processor family	Intel® Pentium® D
Processor frequency	1.6 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor front side bus	800 MHz
Internal memory	0.5 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Memory layout (slots x size)	1 x 0.5 GB
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD-RW
Card reader integrated	Yes
Total storage capacity	160 GB
Platform	PC
Audio input	1
CD read speed	16 x
Mac compatibility	No
External drive bays	2x 5.25\
Networking features	Gigabit Ethernet
Graphics card RAMDAC	400 MHz
Diskette drive memory	1.44 MB
USB 1.1 ports quantity	0
Audio formats supported	AAC, MP3, WAV, WMA
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Non-operating relative humidity (non-condensing)	5 - 95 %
Discrete graphics card model	-
Maximum graphics card memory	0.256 GB
Operating system installed	Windows XP Professional
USB 2.0 ports quantity	8
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Cable lock slot type	Kensington
Power supply	250 W
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, VCCI

Weight and Dimensions

Depth	416 mm
Width	175 mm
Height	353 mm
Weight	9600 g
Package weight	14000 g
