HP Compaq dx2300 User Manual

Eco-Label Certifications &
declarations
This product has received or is in the process of being certified to the following approvals and may be
labeled with one or more of these marks:
US Federal Energy Management Program (FEMP)
IT ECO declaration
EPEAT
Longevity and Upgrading This product is designed to be upgraded, possibly extending its useful life by several years. Spare parts are
available throughout the warranty period and for up to 15 months after the end of production.
Upgradeability features contained in the product include:
6 external USB ports
2 internal USB ports
2 external 5.25" drive bays
2 internal 3.5" drive bays
1 external 3.5" drive bay
1 empty standard PCI slot
2 empty standard PCIe x1 slots
1 empty standard PCIe x16 slot
2 memory slots
1 Serial port
1 Optional second serial port
1 Parallel port
Spare parts are available throughout the warranty period and for up to 5 years after the end of production.
Batteries Batteries used in the product do not contain:
Mercury greater the 5ppm by weight
Cadmium greater than 10ppm by weight
Lead greater than 4000ppm by weight.
Battery size: CR2032 (coin cell)
Battery type: Lithium
Additional Information This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive –
2002/95/EC.
This product is in compliance with California Proposition 65 (State of California; Safe Drinking Water
and Toxic Enforcement Act of 1986).
This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE)
Directive – 2002/96/EC.
This product is in compliance with the IEEE 1680 (EPEAT) standard at the Silver level, see
http://www.epeat.net
Plastics parts weighing over 25 grams used in the product are marked per ISO 11469 and ISO1043.
This product contains 0% recycled materials (by wt.)
This product is >90% recyclable when properly disposed of at end of life.
Packaging Materials
Corrugated Paper – TBD g
EPE Foam – TBD g
LDPE Bag –TBD g
QuickSpecs
HP Compaq dx2300 Microtower Business PC
Technical Specifications - Environmental Data
DA - 12668 North America — Version 17 — May 21, 2008 Page 34

HP Compaq dx2300 Specifications

General

Processor cache	1 MB
Processor cores	2
Processor family	Intel® Pentium® D
Processor frequency	1.6 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor front side bus	800 MHz
Internal memory	0.5 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Memory layout (slots x size)	1 x 0.5 GB
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD-RW
Card reader integrated	Yes
Total storage capacity	160 GB
Platform	PC
Audio input	1
CD read speed	16 x
Mac compatibility	No
External drive bays	2x 5.25\
Networking features	Gigabit Ethernet
Graphics card RAMDAC	400 MHz
Diskette drive memory	1.44 MB
USB 1.1 ports quantity	0
Audio formats supported	AAC, MP3, WAV, WMA
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Non-operating relative humidity (non-condensing)	5 - 95 %
Discrete graphics card model	-
Maximum graphics card memory	0.256 GB
Operating system installed	Windows XP Professional
USB 2.0 ports quantity	8
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Cable lock slot type	Kensington
Power supply	250 W
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, VCCI

Weight and Dimensions

Depth	416 mm
Width	175 mm
Height	353 mm
Weight	9600 g
Package weight	14000 g
