LSI Hi-Speed 56K International Soft Modem (PCIe x1)
X X
Graphics
USDT
SFF
CMT
Intel Graphics Media Accelerator 4500 (integrated)
X X X
Nvidia GeForce 310 DP PCIe x16 Graphics Card
X X
Nvidia Quadro NVS 290 Graphics Card
X X
Nvidia Quadro NVS 295 Graphics Card
X X
ATI Radeon HD 4550 Graphics Card*
X X
ATI Radeon HD 4650 DP (1GB) PCIe x16 Graphics Card
X X
HP ADD2 SDVO + DVI-D Video Adapter
X X
* Not available until January 2010.
HP DisplayPort to DVI-D Adapter
X X X
HP DisplayPort to VGA Adapter
X X X
Audio/Visual
USDT
SFF
CMT
High Definition Audio with Realtek ALC261 codec (all ports are stereo)
X X X
Microphone/Headphone
*
and dedicated headphone front ports
X X X
Line-out and Line-In rear Ports
*
X X X
Multi-streaming capable
*
X X X
Internal Speaker (standard)
X X X
HP Thin USB Powered Speakers
X X X
HP TV Tuner Mini PCIe Card
X
HP TV Tuner PCIe x1 Card
X X
* The front microphone port is re-taskable as a Line-in, Microphone-in or Headphone . Rear audio input ports are re-
taskable as Line-in or Microphone-in. External speakers must be powered externally. Multistreaming can be enabled in
the Realtek control panel to allow independent audio streams to be sent to/from the front and rear jacks. This allows
for different audio applications to use separate audio ports on the system. For example, the front jacks could be used
with a headset for a communications application while the rear jacks are being used with external speakers and a
multimedia application.
Input Devices
USDT
SFF
CMT
PS/2 Standard Keyboard
X X X
USB Standard Keyboard
X X X
USB SmartCard Keyboard
X X X
USB Mini Keyboard
X X X
USB & PS/2 Washable Keyboard
X X X
PS/2 Optical Scroll Mouse
X X X
USB Optical Scroll Mouse
X X X
USB Laser Scroll Mouse
X X X
Miscellaneous
USDT
SFF
CMT
FireWire (IEEE 1394) Card
X X
QuickSpecs
HP Compaq 8000 Elite PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010
Page 13
