Ultra-slim Desktop
Small Form Factor
Convertible Minitower
Dimensions
Chassis
(H x W x D)
2.6 x 9.9 x 10 in
66 x 251.5 x 254 mm
3.95 x 13.30 x 14.9 in
100 x 338 x 378.5 mm
17.63 x 7.00 x 17.5 in
447.8 x 177.8 x 444.5 mm
System Volume
257.5 cu in
4.22 L
790.26 cu in
12.95 L
2160 cu in
35.4 L
Tower Stand
(H x W x D)
1.07 x 4.92 x 6.69 in
27.2 x 124.9 x 169.9 mm
1.12 x 7.01 x 7.87 in
28.5 x 178 x 200 mm
N/A
Packaging
(H x W x D)
8.60 x 15.68 x 19.68 in
218.4 x 398.3 x 499.9 mm
9.00 x 19.68 x 23.38 in
228.6 x 499.9 x 593.85 mm
22.64 x 12.72 x 24.41 in
575.0 x 323 x 620 mm
System Weight
*
6.75 lb
3.07 kg
16.72 lb
7.6 kg
24.54 lb
11.15 kg
Shipping Weight
*
14.42 lb
6.54 kg
17.86 lb
8.1 kg
34.0 lb
15.42 kg
Max Supported Weight
(desktop orientation)
77 lb
35 kg
77 lb
35 kg
77 lb
35 kg
*Configured with 1 hard drive, 1 optical drive, no diskette drive, and no PCI card.
I/O Ports
Ultra-slim Desktop
Small Form Factor
Convertible Minitower
USB 2.0
Front – four (4) ports
Rear – six (6) ports
Serial
N/A
one port standard; second port available optionally
Parallel
N/A
one port available as an option
eSATA
N/A
one port available as an option
PS/2
color coded support for keyboard (purple) and mouse (green)
Video
VGA and DisplayPort provide integrated dual independent monitor support
DVI output
available via optional DisplayPort to DVI Adapter
Audio
Front – microphone & headphone
Rear – line input (supports microphone or line input), line out
NOTE:
See Audio/Visual section for information on re-taskable audio ports.
NIC
Industry standard RJ-45 port accesses the integrated network interface controller
Slots
Ultra-slim Desktop
Small Form Factor
Convertible Minitower
Type and quantity
(1) mini PCI Express
(1) PCI
(2) PCI Express x1
(1) PCI Express x16
(3) PCI
(1) PCI Express x1 (half-
length)
(2) PCI Express x16
Slot specifications
Low profile cards
25W cards
Full height
Primary x16 slot supports
75W or 35W card
Secondary x16 slot supports
35W card
Secondary slot functions
electrically as a x4 slot
PCI Slots
N/A
1 slot
low profile – 2.5"
length – 6.6"
max. power – 25W
3 slots
full height – 4.2"
full length
max. power – 25W
QuickSpecs
HP Compaq 8000 Elite PC
Technical Specifications
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010
Page 18
