Removal and replacement procedures 4–13
Memory module
Before removing the memory module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the battery (see “Battery” on page 4-7).
Remove the memory module:
1. Loosen the two Phillips PM2.5×6.0 captive screws 1 that secure the memory module compartment cover to
the computer.
2. Lift the right side of the cover 2, swing it up and to the left, and remove the cover. The memory module
compartment cover is included in the Plastics Kit, spare part number 486621-001.
Description Spare part number
512-MB, PC2-5300 498473-004
1-GB, PC2-5300 498474-004
2-GB, PC2-5300 498475-004
512-MB, PC2-6400 485031-005
1-GB, PC2-6400 485032-005
2-GB, PC2-6400 485033-005
