Product Features
Rear Panel Components
Rear Panel Components
1 Power Cord Connector 6
n
RJ-45 Network Connector
2
b
PS/2 Mouse Connector 7
l
Parallel Connector
3
a
PS/2 Keyboard Connector 8
c
Monitor Connector
4
o
Universal Serial Bus (USB) 9
k
Headphone/Line-Out Connector
5
m
Serial Connector -
j
Line-In Audio Connector
✎
Arrangement and number of connectors may vary by model.
If a PCI graphics card is installed, the connectors on the card and the system board may be
used at the same time. Some settings may need to be changed in Computer Setup to use both
connectors. For information about Boot Order, refer to the Computer Setup (F10) Utility Guide
on the Documentation CD.
