Computer Setup—Power Management Setup
NOTE: Support for specific Computer Setup options may vary depending on the hardware
configuration.
Table 7 Computer Setup—Power Management Setup
Option Description
After AC Power Loss Allows you to select system power loss behavior:
●
On
●
Off
●
Last State
ACPI Suspend Type Allows you to set type of ACPI sleep mode:
●
S1 (Power On Suspend)
●
S3 (Suspend To RAM)
●
S1 & S3
Wake on PCI Device
from S5
Disables/enables PCI S5 on power on.
External Modem S5
Wake-Up
Disables/enables wake-up modem from S5.
RTC Alarm Resume Disables/enables RTC (real-time clock) alarm.
Date (of Month) If RTC Alarm Resume is enabled, allows you to select the day of the month for resumption of RTC
alarm. (Set to 0 for every day.)
Resume Time
(hh:mm:ss)
If RTC Alarm Resume is enabled, allows you to select what time the RTC alarm will resume.
Computer Setup—PnP/PCI Configurations
NOTE: Support for specific Computer Setup options may vary depending on the hardware
configuration.
Table 8 Computer Setup—PnP/PCI Configurations
Option Description
Reset Configuration
Data
Disables/enables automatic reconfiguration.
The default is Disabled. Select Enabled to reset Extended System Configuration Data (ESCD) when
you exit Setup, if you have installed a new add-on and the system reconfiguration has caused such
a serious conflict that the OS cannot boot.
Resources Controlled
By
Allows you to select whether resources are controlled automatically or manually:
●
Auto (ESCD–Extended Storage Configuration Data)
●
Manual
BIOS can automatically configure all the bootable and Plug-and-Play-compatible devices. If you
choose Auto, you cannot select IRQ, DMA and memory base address fields since BIOS
automatically assigns them.
ENWW Computer Setup (F10) Utilities 9
