HP E27q G4 User Manual

18
Connector repair
This procedure includes VGA, HDMI, Display port, USB3.0, USB A connectors.
The connectors are on the main board (board part number 5E.4QU01.00*).
The connectors identifiers are as follows:
Connector
Location
VGA
J401
HDMI
J601
Display Port
J501
USB 3.0 Type B
JA1
UAB A DUAL
JB1
Before repairing connectors, follow these steps:
▲ Prepare the monitor for disassembly. See Preparation for disassembly on page 11
.
Main Board
J501
J601
J401
JA1
JB1

HP E27q G4 Specifications

General

Color depth	8 bit
Color gamut	99 %
Pixel pitch	0.233 x 0.233 mm
Screen shape	Flat
Pixel density	109 ppi
Display diagonal	27 \
Anti-glare screen	Yes
Display technology	-
Native aspect ratio	16:9
Vertical scan range	50 - 60 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 90 kHz
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display brightness (typical)	250 cd/m²
Pivot angle	90 - 90 °
Tilt angle range	-5 - 23 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
Energy efficiency scale	A to G
Power consumption (max)	60 W
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Feet color	Silver
Certification	BIS; BSMI; CB; CCC; CE; CECP; CEL; EAC; ENERGY STAR®; FCC; ISO 9241-307; KC/KCC; NOM; PSB; SEPA; TCO Certied; TCO Certied Edge; TUV LBL; TUVS; VCCI; WEEE; ISC; California Energy Commission (CEC); WW application; ICE; TGM; TUV-GS
Product color	Black, Silver
Front bezel color	Black
Market positioning	Business
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	4
Number of USB Type-B upstream ports quantity	1
Package depth	444 mm
Package width	695 mm
Package height	225 mm
Package weight	10500 g

Weight and Dimensions

Depth (with stand)	216 mm
Width (with stand)	613.3 mm
Height (with stand)	536 mm
Weight (with stand)	7000 g
Depth (without stand)	47 mm
Height (without stand)	366.1 mm
