HP ENVY User Manual

Battery
Description Spare part number
3-cell, 48-Wh, 4.21-Ah, Li-ion battery (Besy Buy SKUs) 807417-005
3-cell, 55-Wh, 4.56-Ah, Li-ion battery 805094-005
Before removing the battery, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see Bottom cover on page 35).
Remove the battery:
WARNING! To reduce potential safety issues, use only the user-replaceable battery provided with the
computer, a replacement battery provided by HP, or a compatible battery purchased from HP.
CAUTION: Removing a user-replaceable battery that is the sole power source for the computer can cause
loss of information. To prevent loss of information, save your work or shut down the computer through
Windows before removing the battery.
1. Remove the ve Phillips PM2.5×4.0 screws (1) that secure the battery to the computer.
2. Disconnect the battery cable from the system board (2).
3. Remove the battery (3) from the computer.
Reverse this procedure to install the battery.
54 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

HP ENVY Specifications

General

Bus type	DMI
Stepping	D2
Tjunction	100 °C
Processor cache	6 MB
Processor cores	4
Processor model	i7-2630QM
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-2600 Mobile Series
Processor socket	Socket 988
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	2 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.9 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	45 W
CPU multiplier (bus/core ratio)	20
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel HM67 Express
HDD speed	5400 RPM
HDD capacity	750 GB
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	-
Total storage capacity	1500 GB
Number of HDDs installed	2
Display diagonal	17.3 \
Native aspect ratio	16:9
Display number of colors	16.78 million colors
Type	PC
Power supply type	AC/DC
Power requirements	100 - 240V
AC adapter included	Yes
Wireless technology	Wi-Fi
Graphics card family	AMD
Compliance industry standards	802.11a/b/g/n
Maximum internal memory (64-bit)	16 GB
Memory slots	4x SO-DIMM
Internal memory	8 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
On-board graphics card ID	0x116
Discrete graphics card model	AMD Radeon HD 6850M
On-board graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Audio system	HD
Keyboard layout	AZERTY
Pointing device	Touchpad + Scroll zone
Networking type	10/100/1000
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Home Premium
Charging port type	DC-in jack
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
Password protection type	BIOS, HDD
Battery life (max)	2.25 h
Number of battery cells	6
AC adapter power	120 W
Sustainability certificates	EPEAT Silver
Product color	Black, Silver
Country of origin	China
Processor code	SR02Y
Processor ARK ID	52219
Processor package size	37.5 x 37.5 (rPGA998) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	275 mm
Width	416 mm
Height	38.7 mm
Weight	3410 g
