HP Ethernet 10Gb 2-port 530T Adapter User Manual

Specifications 11
Specifications
UTP cable specifications
The HP Ethernet 10Gb 2-port 530T adapter can use existing UTP CAT6 (or better) cable to deliver Gigabit
Ethernet over copper, according to the IEEE 802.3an specifications. For new installations, CAT6a cable is
recommended.
Maximum distances for CAT6 cable are 30 meters (98 feet). Maximum distances for CAT6a are 100 meters
(328 feet).
To connect to the network, the HP Ethernet 10Gb 2-port 530T uses the following cable for 10GBase-T
transmission:
• CAT6 UTP or better twisted-pair
• 22-26 AWG, 100Ω @ 1 MHz
• EIA/TIA 568-B.2-10b
General specifications
Specification Value
Controller
Broadcom 57810S (Meru) and 10GBaseT PHY (84833)
Data rate
10 Gb/s per port, 20 Gb/s combined, full-duplex
PCI bus
PCI Express x8 Gen2.1
Connectors
Two 10GBase-T
Dimensions (LxW)
16.76 cm x 6.89 cm (6.6 inches x 2.7 inches) without bracket
Compliance
Compliance Standard
IEEE
IEEE 802.3az (EEE), IEEE802.3, IEEE802.3ap, IEEE802.3xx, IEEE802.2x,
IEEE802.3ad, 802.1Qaz, 802.1Qau, 802.1Qbb, 802.1Qbg, 802.1Qbh
Safety
UL Mark (US and Canada)
EN 60950
