Specifications
Maintenance and Service Guide 6–3
Hard drive specifications
500 GB* 320 GB* 250 GB*
Dimensions
Height 9.5 mm 9.5 mm 9.5 mm
Width 70 mm 70 mm 70 mm
Weight 115 g 115 g 115 g
Interface type SATA SATA SATA
Transfer rate 140 MB/sec 140 MB/sec 140 MB/sec
Security ATA security ATA security ATA security
Seek times (typical read, including setting)
Single track 3 ms 3 ms 3 ms
Average 13 ms 13 ms 13 ms
Maximum 24 ms 24 ms 24 ms
Logical blocks 976, 773, 168 625,142, 448 488, 376,120
Disc rotational speed 7200 rpm 7200 rpm 7200 rpm
Operating temperature 5°C to 55°C (41°F to 131°F)
*1 GB = 1 billion bytes when referring to hard drive storage capacity. Actual accessible capacity is less. Actual drive
specifications might differ slightly.
✎
Certain restrictions and exclusions apply. Contact technical support for details.
