1-1
1
Getting Started
This chapter describes how to make the initial connections to the switch and provides an overview of the web
interface.
Connecting the Switch to a Network
To enable remote management of the switch through a web browser, the switch must be connected to the network.
The switch is preconfigured with an IP address for management purposes. After initial configuration, the switch
can also be configured to acquire its address from a DHCP server on the network.
By default, the switch is assigned the following static IP information for access to the web interface:
■ IP address: 192.168.1.1
■ Network mask: 255.255.255.0
■ Gateway: 0.0.0.0
1. Connect the switch to the management PC or to the network using any of the available network ports.
2. Power on the switch.
3. Set the IP address of the management PC’s network adaptor to be in the same subnet as the switch.
Example: Set it to IP address 192.168.1.2, mask 255.255.255.0.
4. Enter the IP address shown above in the web browser. See page 1-3 for web browser requirements.
Thereafter, use the web interface to configure a different IP address or configure the switch as a DHCP client
so that it receives a dynamically assigned IP address from the network.
Note ■ If you enable DHCP for IP network configuration, the switch must be connected to the same network
as the DHCP server. You will need to access your DHCP server to determine the IP address assigned
to the switch.
■ The switch supports LLDP (Link Layer Discovery Protocol), allowing discovery of its IP address from
a connected device or management station.
■ If DHCP is used for configuration and the switch fails to be configured, the IP address 192.168.1.1 is
assigned to the switch interface.
After the switch is able to communicate on your network, enter its IP address into your web browser’s address
field to access the switch management features.
