7-6
Link Layer Discovery Protocol (LLDP and LLDP-MED)
LLDP Remote Device Summary
LLDP Remote Device Summary
Use the LLDP Remote Device Summary page to view information about remote devices for which the switch
has received LLDP information. Interfaces that have this option enabled display in this table only if they have
received LLDP notifications from a remote device.
To display the Remote Device page, click LLDP > Remote Devices in the navigation pane.
Figure 7-4. LLDP Remote Device Summary Page
Table 7-5. LLDP Remote Device Summary Fields
Field Description
Interface The HP 1820 interface that received the LLDP data from the remote system.
Remote ID The identifier assigned to the remote system that sent the LLDPDU.
Chassis ID The hardware platform ID for the remote system.
Port ID The physical address of the port on the remote device that sent the LLDP data.
Port Description The port description configured on the remote device. If the port description is not
configured, the field is blank.
System Name The system description configured on the remote device. If the system description is not
configured, the field is blank.
Capabilities Supported The capabilities on the remote device. The possible capabilities include other, repeater,
bridge, WLAN AP, router, telephone, DOCSIS cable device, and station.
Capabilities Enabled The capabilities on the remote device that are enabled.
System IP The reported management IP addresses of the remote device. The system IP address
provides a link to the web interface on the remote device.
