HP L1506 User Manual

15" LCD Color Monitor HP L1506
74
12. Different Parts List
Diversity of T56CM4DKABHPNE compared with T54VM4DCABHANE
Location Part No. Description
CBPC6CM4HPQ2P MAIN BOARD FOR 15
PWPC1521CH1P POWER BOARD FOR 15"
E095 S95G801820559 WIRE HARNESS
15G8159 3 MAIN FRAME
89G1738CAAE01 SIGNAL CABLE
E089A 89G402A19N IS AC POWER CABLE
750GLC50P1Q12Z000H PANEL CLAA150XP01Q 000
H41G160069033E DOC KIT FOR NA(391904-D
CN201 33G8027 12 6065 WAFER 2*6P 2.0MM R/A
PT801 S80GL15T20V TRANSFORMER BY TPV
CN801 33G8020 2D U WAFERG
CN802 33G8020 2D U WAFER
CN901 33G8029 5A WAFER
C901 65G305M2222BP 2200PF +-20%
C902 65G305M2222BP 2200PF +-20%
C921 65G306M4722BP 4700PF +-20% 400VAC
C845 67G215V102 3N ELCAP 1000UF +-20% 16V
L901 73L 174 55 HG GP GBQM4.778.392
R805 61G0805102 6857 RST CHIPR 1KOHM +-5% 1/
R837 61G0805102 6857 RST CHIPR 1KOHM +-5% 1/
R923 61G0805102 6857 RST CHIPR 1KOHM +-5% 1/
R924 61G0805102 6857 RST CHIPR 1KOHM +-5% 1/
R926 61G0805102 6857 RST CHIPR 1KOHM +-5% 1/
R824 61G0805103 6857 RST CHIPR 10KOHM +-5% 1
R828 61G0805103 6857 RST CHIPR 10KOHM +-5% 1
R832 61G0805103 6857 RST CHIPR 10KOHM +-5% 1
R919 61G0805103 6857 RST CHIPR 10KOHM +-5% 1
R840 61G0805104 6857 RST CHIPR 100KOHM +-5%
R842 61G0805104 6857 RST CHIPR 100KOHM +-5%
R835 61G0805105 6857 RST CHIPR 1MOHM +-5% 1/
R844 61G0805105 6857 RST CHIPR 1MOHM +-5% 1/
R802 61G0805134 6857 RST CHIPR 130KOHM +-5%
R911 61G0805151 6857 RST CHIPR 150 OHM +-5%
R925 61G0805202 6857 RST CHIPR 2KOHM +-5% 1/
R836 61G0805204 6857 RST CHIPR 200KOHM +-5%
R819 61G0805220 6857 RST CHIPR 22 OHM +-5% 1
R820 61G0805220 6857 RST CHIPR 22 OHM +-5% 1

HP L1506 Specifications

General

3D	No
Pixel pitch	0.297 x 0.297 mm
Aspect ratio	4:3
Response time	8 ms
Display diagonal	15 \
Display resolution	1024 x 768 pixels
Vertical scan range	56 - 76 Hz
Horizontal scan range	30 - 61 kHz
Viewing angle, vertical	100 °
Contrast ratio (dynamic)	-
Contrast ratio (typical)	450:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	130 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	720 x 400, 832 x 624, 1024 x 768 (XGA), 640 x 480 (VGA), 800 x 600 (SVGA)
On/off switch	Yes
DVI-D ports quantity	0
Tilt angle range	-5 - 30 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	23 W
Power consumption (standby)	2 W
Power consumption (typical)	21 W
Certification	CISPR, VCCI, CSA, TUV, GS, CCC, MIC, FCC, UL, GOST, SASO
Product color	Silver
Country of origin	China
Market positioning	Business
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Package weight	4500 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	203 mm
Height (with stand)	355 mm
Weight (with stand)	3200 g
Depth (without stand)	60 mm
Width (without stand)	340 mm
Height (without stand)	290 mm
Weight (without stand)	- g
