HP L1910 User Manual

19" LCD Color Monitor HP L1910
23
7.2 Power Board
715G2655 1 2
D905 31DQ06FC 3
R930
2.43K OHM 1% 1/10W
R918
100 OHM +-5% 1/4W
C900
0.0033uF/250V
C910
0.001uF
C903
0.22uF/275V
T901
POWER X'FMR
7
8
9
10
11
12
4
5
6
1
2
+
C940
1000uF/16V
!
F901
FUSE
R909
5.1 OHM +-5% 1/4W
+
C916
1000uF/25V
!
C924
0.1uF
ZD922
RLZ5.6B
1 2
!
L903
1.1uH
R921
100 OHM +-5% 1/4W
!
R939
1K 1/8W
+
C907
120uF/450V
R923
100 OHM +-5% 1/4W
IC902
PC123X2YFZOF
12 43
C911
0.0022uF
ZD902
RLZ13B
1 2
+
C908
22uF/50V
+
C917
680uF/25V
R905
300KOHM +-5% 1/4W
GND 1 (009G6005 1)
CN901
SOCKET
12
3
C930
0.1uF
R924
150OHM +-1% 1/8W
!
R927
3K9 1/10W
R935
100 OHM +-5% 1/4W
IC901
LD7552CPS
1
2
3
4 5
6
7
8
GND
COMP
VCC
RT NC
CS
VCC
OUT
R942
1K 1/10W 1%
FB901
BEAD
12
R922
100 OHM +-5% 1/4W
+12V
R901
1M 1/4W
R910
10R 1/4W
F903
FUSE
ON/ OFF
R920
100 OHM +-5% 1/4W
!
ZD923
RLZ5.6B
1 2
C936
0.0015uF/1KV
HS2 with Heat-sink(090G6263 1)
D901
UF4003PT
ZD906
RLZ22B
1 2
F902
FUSE
!
C928
0.01uF
D906
SP10150
1
2
3
R943
470R 1/8W
HS1 with Heat-sink(090G6263 1)
R906
300KOHM +-5% 1/4W
Q901
STP10NK70ZFP
C913
0.1uF
L905
1.1uH
C902
0.0022uF/250V
C937
0.0015uF/1KV
CN902
CONN
1
2
3
4
5
6
7
8
9
10
+5V
R904
300KOHM +-5% 1/4W
!
+
C939
1000uF/16V
+
C921
470uF/16V
R926
1K 1/10W 1%
R938
10K 1/8W
3.15A
250V
C901
0.0022uF/250V
HS5 with Heat-sink (90G6064 1)
!
+5V
C909
470pF/50V
C912
0.001uF
R902
1M 1/4W
R946
150OHM +-5% 1W
2.0A 250V
D903
LL4148WP
R914
0.47 OHM +-5% 2WS
t
NR901
NTCR
R961
100 OHM +-5% 1/4W
R915
100K 1/8W
Q903
PMBS3904
C932
0.001uF
R919
100 OHM +-5% 1/4W
4A 250V
GND 2 (009G6005 1)
AUDIO_5V
MUTE
ZD921
RLZ13B
1 2
R903
100KOHM +-5% 2WS
DIM
+
C918
680uF/25V
R925
1K 1/8W
C931
0.1uF
+
C915
470uF/16V
R912
220 OHM +-5% 1/4W
TPV MODEL 1. 0
HP L1950 & L1750
Cus tom
23
Thursday , August 02, 2007
715G2655-1
< 称爹 >
PO WER
G2655-1-X-X-1-070802
OEM MODEL Si ze
Rev
Date
Sheet
of
TPV MOD EL
PCB NAME
称爹
T P V ( Top Victory Elect ronics Co . , Ltd. )
Key Component
絬 隔 瓜 絪 腹
L904
1.1uH
D907
SP1060
1
2
3
C929
0.001uF
!
L902
L
1 4
2 3
C938
4700 PF/1KV
!
!
+5V
VOL
C905
0.22uF/275V
C904
0.001uF/250V
C906
0.0015uF/2KV
FB902
BEAD
12
R962
100 OHM +-5% 1/4W
R940
33K 1/10W
-
+
BD901
GBU408
2
1
3
4
IC903
AZ431AZ-AE1
!
D900
BA159GPT
R947
100 OHM +-5% 1/4W

HP L1910 Specifications

General

3D	No
Panel type	TN
Pixel pitch	0.294 x 0.294 mm
Aspect ratio	5:4
Display diagonal	19 \
Display resolution	1280 x 1024 pixels
Display technology	LED
Vertical scan range	50 - 77 Hz
Horizontal scan range	24 - 83 kHz
Viewable size diagonal	303 mm
Viewable size, vertical	378 mm
Contrast ratio (typical)	800:1
Display number of colors	-
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	720 x 400, 832 x 624, 1152 x 870, 1024 x 768 (XGA), 640 x 480 (VGA), 800 x 600 (SVGA)
On/off switch	Yes
HDMI ports quantity	0
Product color	Carbon, Silver
Country of origin	China
Market positioning	Business
Tilt angle range	-5 - 25 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Power consumption (standby)	2 W
Power consumption (typical)	31 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth (with stand)	192 mm
Height (with stand)	415 mm
Weight (with stand)	4900 g
Depth (without stand)	58 mm
Width (without stand)	414 mm
Height (without stand)	347 mm
Weight (without stand)	3900 g
