HP L1910 User Manual

19" LCD Color Monitor HP L1910
4
2. LCD Monitor Description
The LCD Monitor will contain main board, power board, a key board which house the flat panel control logic, brightness
control logic and DDC.
The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips each
voltage.
Video signal, DDC
Power Board
(
Include ada
p
ter board
)
Flat Panel and
CCFL backlight
Main Board
RS232 Connector
For white balance
adjustment in
factory mode
HOST Computer
CCFT Drive.
AC-IN
110V-240V
Monitor Block Diagram
Keyboard

HP L1910 Specifications

General

3D	No
Panel type	TN
Pixel pitch	0.294 x 0.294 mm
Aspect ratio	5:4
Display diagonal	19 \
Display resolution	1280 x 1024 pixels
Display technology	LED
Vertical scan range	50 - 77 Hz
Horizontal scan range	24 - 83 kHz
Viewable size diagonal	303 mm
Viewable size, vertical	378 mm
Contrast ratio (typical)	800:1
Display number of colors	-
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	720 x 400, 832 x 624, 1152 x 870, 1024 x 768 (XGA), 640 x 480 (VGA), 800 x 600 (SVGA)
On/off switch	Yes
HDMI ports quantity	0
Product color	Carbon, Silver
Country of origin	China
Market positioning	Business
Tilt angle range	-5 - 25 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Power consumption (standby)	2 W
Power consumption (typical)	31 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth (with stand)	192 mm
Height (with stand)	415 mm
Weight (with stand)	4900 g
Depth (without stand)	58 mm
Width (without stand)	414 mm
Height (without stand)	347 mm
Weight (without stand)	3900 g
