HP LP3065 User Manual

Turning on the Monitor
1. Press the power switch to turn on the computer.
2. Press the master power switch on the rear of the LCD.
3. Press the power button on the front of the monitor.
CAUTION Burn-in image damage may occur on monitors that display the same static image
on screen for a prolonged period of time.* To avoid burn-in image damage on your monitor
screen, you should always activate a screen saver application or turn off the monitor when it is
not in use for a prolonged period of time. Image retention is a condition that may occur on all LCD
screens.
* A prolonged period of time is 12 consecutive hours of non-use.
Connecting USB Devices
The monitor provides four USB connectors on the side panel to connect devices such as a digital
camera, USB keyboard, or USB mouse.
NOTE You must connect the USB hub cable from the monitor to the computer to enable the
USB 2.0 ports on the monitor. Refer to Step 2 in
Connecting the Monitor.
Figure 3-10 Connecting USB Devices
Using the Accessory Rails
The monitor features accessory rails on the rear that may be used to mount optional devices, such as
the HP speaker bar, to attach to the LCD. Refer to the documentation included with your optional device
for detailed mounting instructions.
ENWW Turning on the Monitor 11

HP LP3065 Specifications

General

Pixel pitch	0.250 mm
Response time	6 ms
Display diagonal	30 \
Display resolution	2560 x 1600 pixels
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display scanning frequency	Horizontal frequency: 100 kHz, Vertical frequency: 60 Hz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	2560 x 1600 (WQXGA)
UNSPSC-code	43211902
On/off switch	Yes
Audio included	No audio includedNo audio included at platform level
Security features	Kensington Lock-ready
Weight (imperial)	Unpacked30.6 lb lbs
Power requirements	Auto-Sensing, 100 to 240 VAC, 50 +/-3 Hz to 60 +/-3 Hz)
Display resolution at frequency	2560 x 1600 @ 60 Hz (native)
Dimensions (W x D x H) (imperial)	27.2 x 3.3 x 17.9 \
Product dimensions (with stand, imperial)	27.2 x 9.5 x 23.2 \
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Non-operating relative humidity (non-condensing)	5 - 85 %
Tilt angle range	-5 - 30 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (standby)	2 W
Power consumption (typical)	118 W
Certification	Australian ACA Approval, Canadian Requirements/CSA, CE Marking, China CCIB/CCEE Approval, CISPR Requirements, Eastern European Approvals, FCC Approval, German Ergonomic (TUV and GS Mark), ISO 9241-3, 7, 8 VDT Guidelines, ISO 13406-2 Pixel Defect Guidelines, Mexican NOM Approval, MIC Requirements (New Zealand), MPR-II Compliant, Nordic Approvals (Nemko, Fimko, Demko, Semko), S. Korean MIC Approval, Taiwan BSMI Approval, TCO 99 (emissions, ergonomics, environment), TUV-Ergo, UL Listed, VCCI Approvals, Microsoft Windows Certification (Microsoft Windows 98, Microsoft Windows 2000, and Microsoft Windows XP)
Product color	Black
Country of origin	China
I/O ports	One upstream, four downstream USB 2.0 Hub ports (cable included)
USB hub version	2.0
DVI-D ports quantity	3
DVI-I ports quantity	0
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	4

Weight and Dimensions

Depth (with stand)	240 mm
Height (with stand)	590 mm
Weight (with stand)	13400 g
Depth (without stand)	84 mm
Width (without stand)	692 mm
Height (without stand)	455 mm
