10.1-inch WSVGA display specifications
Metric U.S.
Dimensions
Height 23.5 cm 9.3 in
Width 14.3 cm 5.6 in
Diagonal 25.7 cm 10.1 in
Number of colors 262,144
Contrast ratio 500:1 (typical)
Brightness 200 nits (typical)
Pixel resolution
Pitch 0.2175 × 0.2088 mm
Format 1024 × 600
Configuration RGB vertical stripe
Backlight LED
Character display 80 × 25
Total power consumption 3.46 W
Viewing angle ±45° horizontal, +15/–35° vertical (typical)
10.1-inch WSVGA display specifications
93
