Display assembly subcomponents
Item Component Spare part number
(1) Display bezel:
For use only on Compaq Mini CQ10 computer models 658504-001
For use only on HP Mini 110 computer models 658503-001
(2) Webcam/microphone module 658516-001
(3) 10.1-in, LED, BrightView, WSVGA display panel 658511-001
(4) Display Hinge Kit (includes left and right display hinges and brackets) 650711-001
(5) Display Cable Kit (includes display panel cable and webcamera/microphone
module cable)
658505-001
(6) Antenna Kit (includes left and right wireless antenna cables and transceivers) 658498-001
(7) Display enclosure
26 Chapter 3 Illustrated parts catalog
