Memory module
Description Spare part number
2048-MB, PC2-5300, 533-MHz, DDR2 (Not supported by computers with Windows® XP Home SP3,
ultra low-cost personal computer (ULCPC) edition installed.)
577971-001
1024-MB, PC2-5300, 533-MHz, DDR2 577970-001
Before removing the memory module, follow these steps:
1. Shut down the device. If you are unsure whether the device is off or in Hibernation, turn the device
on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the device.
3. Disconnect the power from the device by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the device.
4. Remove the battery (see
Battery on page 32).
5. If your device has WWAN capability, remove the SIM (see
SIM on page 33).
Remove the memory module:
1. Use a fingernail or other flexible tool (1) to release the memory module compartment cover from
the computer.
2. Swing the cover up and away from the outside of the computer (2), and then remove the
cover (3).
3. Spread the retaining tabs (1) on each side of the memory module slot to release the memory
module. (The module tilts up.)
34 Chapter 4 Removal and replacement procedures
