Display assembly
Description Spare part number
Display assembly (includes 1 webcam, 2 microphones, and 2 WLAN antenna
transceivers/cables; WWAN is optional)
●
10.1-inch, high-definition, AntiGlare display assembly with webcam (includes
WWAN)
580616-001
●
10.1-inch, high-definition, AntiGlare display assembly with webcam
577969-001
●
10.1-inch, standard-definition, AntiGlare display assembly with webcam (includes
WWAN)
580615-001
●
10.1-inch, standard-definition, AntiGlare display assembly with webcam
577968-001
Display bezel 577929-001
Display Hinge Kit
(Includes left and right display panel hinges)
577930-001
Webcam module 577927-001
Display panel/webcam cable
●
For use with high-definition display assembly
577932-001
●
For use with standard-definition display assembly
577931-001
Display Cable Kit (includes microphone assembly cable, WLAN antennas, and
WWAN antennas)
577933-001
Display enclosure (includes logo) 577928-001
Before removing the display assembly, follow these steps:
1. Shut down the device. If you are unsure whether the device is off or in Hibernation, turn the device
on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the device.
3. Disconnect the power from the device by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the device.
4. Remove the battery (see
Battery on page 32).
5. If your device has WWAN capability, remove the SIM (see
SIM on page 33).
6. Remove the following components:
a. Keyboard (see
Keyboard on page 36)
b. Hard drive (see
Hard drive on page 39)
c. Top cover (see
Top cover on page 44)
52 Chapter 4 Removal and replacement procedures
