5–56 Maintenance and Service Guide
Removal and Replacement Procedures
5.22 Modem Module
1. Prepare the computer for disassembly (Section 5.3),
and then remove the following components:
a. Hard drive (Section 5.4)
b. Memory/Mini Card module cover (Section 5.7)
c. Optical drive (Section 5.9)
d. Keyboard (Section 5.10)
e. Switch cover (Section 5.17)
f. Display assembly (Section 5.18)
g. Top cover (Section 5.19)
Modem Module Spare Part Number Information
Modem module 399441-001
