HP OMEN 27 User Manual

4
2 Monitor features
This chapter provides an overview of the monitor’s features.
Features
Depending on the model, your monitor might include the following features:
Display features
● 68.6 cm, 27-in screen with 1920 × 1080 @ 165 Hz FHD resolution, plus full-screen support for lower
resolutions; includes custom scaling for maximum image size while preserving original aspect ratio
● Liquid crystal display (LCD) with active matrix and in-plane switching (IPS) (select models)
● VA panel technology (select models)
● Wide color gamut to provide coverage of sRGB/DCI-P3 color spaces
● Nonglare panel with an LED backlight
● Wide viewing angle to allow viewing from a sitting or standing position, or moving from side to side
● Tilt, swivel, and height adjustment capabilities
● Pivot capability to rotate the monitor head from landscape to portrait orientation (select models)
● On-screen display (OSD) adjustments in several languages for easy setup and screen optimization
● Energy saver feature to meet requirements for reduced power consumption
● Cable management feature for placement of cables and cords
Connectors
● DisplayPort™ video input (cable included)
● High-Definition Multimedia Interface® (HDMI) video input(2)
● Audio-out (headphone) jack
● Plug and Play capability, if supported by your operating system
Monitor stand
● Removable stand for flexible monitor head mounting solutions
● HP Quick Release 2 device to quickly attach the monitor head to the stand with a simple click, and then
remove it with the convenient sliding tab release
● VESA® mounting bracket for attaching the monitor head to a wall-mount device or swing arm
● VESA mounting capability (100 × 100 mm) for attaching the monitor to a swing arm mount
● Support for a mounting bracket to attach the monitor to a workstation
NOTE: For safety and regulatory information, refer to the Product Notices provided on your optical disc or in
your documentation kit. To locate updates to the user guide for your product, go to http://www.hp.com/
support and select your country. Select Find your product, and then follow the on-screen instructions.

HP OMEN 27 Specifications

General

3D	No
Panel type	TN
Color gamut	72 %
Pixel pitch	0.233 x 0.233 mm
Aspect ratio	16:9
Screen shape	Flat
Display surface	Matt
Display diagonal	27 \
Display technology	LED
Vertical scan range	30 - 144 Hz
Horizontal scan range	34 - 222 kHz
Supported video modes	1080p, 1440p
Viewing angle, vertical	160 °
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	170 °
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080), 2560 x 1440
On/off switch	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
VGA (D-Sub) ports quantity	0
Certification	CE, CB, KC/KCC/NOM/PSB/ICE/TUV-S/ISO 9241-307/ EAC/UL/CSA/PSB/ISC/CCC/CEL/CECP/SEPA/TCO/TCO Certified Edge/ISC/VCCI/FCC/BSMI/Vietnam MEPS/Australian-New Zealand MEPS/WEEE
Product color	Black
Country of origin	China
Market positioning	Gaming
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Sustainability certificates	ENERGY STAR
LED indicators	Power
Tilt angle range	-5 - 23 °
Number of OSD languages	10
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, DUT, ENG, ESP, FRE, ITA, JPN, POR
Power consumption (standby)	0.5 W
Power consumption (typical)	75 W
Package type	Box
Package depth	267.9 mm
Package width	755.9 mm
Package height	482 mm
Package weight	10477.98 g
Cables included	DisplayPort, HDMI, USB
Quantity per pallet	16 pc(s)
Number of layers per pallet	4 pc(s)

Weight and Dimensions

Depth (without stand)	272.5 mm
Width (without stand)	613.6 mm
Height (without stand)	535.1 mm
Weight (without stand)	6481.835 g
