16
Power board
The power board part number is 1
st
Source ADPCM1614AA1 and 2
nd
Source LNPCMH261GQA1.
Before removing the power board, follow these steps:
▲ Prepare the monitor for disassembly. See Preparation for disassembly on page 11.
Remove the power board:
1) The HP OMEN 27qs power board connector position is as follows:
2) Locate the part number location on the board.
CN9101
Warning: After unplugging the
power supply, the capacitance
is still charged, do not touch
and discharge the capacitor.

HP OMEN 27qs Specifications

General

Depth	52.2 mm
Width	613.6 mm
Height	364.3 mm
Weight	7900 g
Package depth	160 mm
Package width	699 mm
Package height	446 mm
Package weight	11260 g
Pixel pitch	0.23 x 0.23 mm
Screen shape	Flat
Pixel density	109 ppi
Display diagonal	27 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	-
Native aspect ratio	16:9
Maximum refresh rate	240 Hz
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	68.6 cm
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	1280 x 1024 (SXGA), 720 x 400, 1280 x 800, 800 x 600 (SVGA), 1440 x 900 (WXGA+), 1600 x 900, 1024 x 768 (XGA), 1680 x 1050 (WSXGA+), 640 x 480 (VGA), 1920 x 1080 (HD 1080), 1280 x 720 (HD 720)
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50/60 Hz
Power consumption (max)	106 W
Power consumption (standby)	0.5 W
Power consumption (typical)	54 W
Built-in camera	No
RMS rated power	3 W
Number of speakers	2
Product color	Black
Country of origin	China
Market positioning	Gaming
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	20 - 80 %
Operating relative humidity (H-H)	5 - 95 %
DisplayPort version	1.4
AMD FreeSync type	FreeSync Premium
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 20 °
Panel mounting interface	100 x 100 mm

Weight and Dimensions

Depth (with stand)	223.3 mm
Height (with stand)	523.7 mm
