HP P24 G5 User Manual

9
How to order parts
The HP authorized repair center can purchase the power board from HP.
Power board
Description
HP spare part number
Manufacturer part number
PSU P24 G5 1
st
source
N16739-001
PLPCLC411GQB4
PSU P24 G5 2
nd
source
N16740-001
PLPCLE601KQB5
PSU P24 G5 3
rd
source
N16739-003
PLPCLE481AQB1
Capacitors and connectors are available for purchase from the following EU distributors:
 Farnell: Farnell UK - Electronic Components Distributor
 RS Component: Capacitors | RS Components (rs-online.com)
 Tme Component: Transfer Multisort Elektronik
Capacitors by distributor
Component description
Location
Component
distributor
Distributor part number
EC 470uF 20% 25V 10x12
5000 hr 1.7A ECR1
C916
NA
Contact HP Support
Connectors by manufacturer
Component description
Location
identifier
Component
distributor
Distributer part number
DisplayPort
CN501
Farnell
DP1RD20JQ1
(JAE)
HDMI
CN502
RS
SD-47151-001
(Molex)
D-SUB
CN503
tme
HDL15-SL-B
(ADAM TECH)
NOTE: Rear cover and chassis need to be modified to hold connector. Connector may need modifications to
meet functional, safety and regulatory requirements accordingly if it doesn’t match exactly.
15
REAR_COVER L238W-Fhp1b-s1
1
16
MAIN BOARD
1
S1
0M1G3030 4120
11
S2
0D1G1030 6120
3
S3
QM1G38400601200ARA
1
S4
0Q1G3030 6 47 CR3
2
S5
QQ1G24200301200AWL
2
S6
0M1G3030 4 47 CR3
2
S7
0M1G2940 10 47 CR3
4

HP P24 G5 Specifications

General

Color gamut	72 %
Pixel pitch	0.27 x 0.27 mm
Screen shape	Flat
Pixel density	93 ppi
Backlight type	Edge LED
Display diagonal	23.8 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	48 - 75 Hz
Maximum refresh rate	75 Hz
Horizontal scan range	30 - 86 kHz
Contrast ratio (dynamic)	8000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
HDMI version	1.4
DisplayPort version	1.2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	30 W
Power consumption (standby)	0.5 W
Power consumption (typical)	20 W
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	124 mm
Package width	595 mm
Package height	391 mm
Package weight	5940 g
Tilt angle range	-5 - 23 °
Panel mounting interface	100 x 100 mm
Cables included	AC, HDMI
Product color	Black
Market positioning	Business
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	180.5 mm
Width (with stand)	538.9 mm
Height (with stand)	397.9 mm
Weight (with stand)	3780 g
Depth (without stand)	51.4 mm
Height (without stand)	323.6 mm
