HP Pavilion 14 User Manual

Reverse this procedure to install the WLAN module.
Optical drive
NOTE: The optical drive spare part kit includes a bezel and bracket.
Description Spare part number
Optical drive, SuperMulti DVD±R/RW Double-Layer Drive (includes bezel, bracket, and screws) 734415-001
Before removing the optical drive, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 49).
Remove the optical drive:
1. Using a small Phillips screwdriver, remove the Phillips M2.5×6.5 screw that secures the optical
drive to the computer (1).
2. Using the screwdriver, push on the rear of the optical drive to disconnect it from the computer
Component replacement procedures
55

HP Pavilion 14 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Red
Country of origin	China
Processor cache	2 MB
Processor cores	4
Processor model	A8-7410
Processor family	AMD A8
Processor socket	Socket FT3b
Processor frequency	2.2 GHz
Processor cache type	L2
Processor manufacturer	AMD
Processor boost frequency	2.5 GHz
Internal memory	8 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3L-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 8 GB
HDD speed	5400 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	No
Card reader integrated	Yes
Total storage capacity	1000 GB
Compatible memory cards	SD
Panel type	SVA
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Discrete graphics card model	Not available
On-board graphics card model	AMD Radeon R5
Number of built-in speakers	2
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Ethernet LAN data rates	10, 100 Mbit/s
USB 2.0 ports quantity	1
VGA (D-Sub) ports quantity	0
Sustainability certificates	EPEAT Silver, ENERGY STAR
Cable lock slot type	Kensington
AC adapter power	45 W
Battery capacity	41 Wh
Number of battery cells	3
Bundled software	HP ePrint HP Games Powered by WildTangent HP Support Assistant software included McAfee LiveSafe Netflix Dropbox CyberLink PowerDirector TripAdvisor
Operating system architecture	64-bit
Pointing device	Touchpad

Weight and Dimensions

Depth	224 mm
Width	338 mm
Height	19.5 mm
Weight	1780 g
