HP Pavilion dm4 User Manual

Spare part
number
Description
608273-001 Power connector with cable
608277-001 USB board with cable
609939-001 65-W AC adapter
609940-001 90-W AC adapter
609947-001 90-W AC adapter for use in India
609948-001 65-W AC adapter for use in India
613585-001 Intel Core i5 450M Dual Core processor (2.40-GHz, 3-MB L3 cache)
613666-001 35.56 cm (14.0-in) display panel, high definition, BrightView for use in models with WWAN
613667-001 35.56 cm (14.0-in) WXGA Brightview display assembly for use in models equipped with WWAN
615744-001 Webcam module
616244-001 System board (includes replacement thermal material) for use in models with 1 GB of HD5450 discrete
graphics memory
619997-001 Intel® Centrino® Advanced–N + WiMAX 6250 WLAN module for use in the United States
621044-001 System board for use in models equipped with 512 MB of HD5470 discrete graphics memory
621045-001 System board for use in models equipped with 1 GB of HD5470 discrete graphics memory
625824-001 Intel Core i5 560M Dual Core processor, 2.66-GHz, (SC turbo up to 3.2-GHz), 3-MB L3 cache
625825-001 Intel Core i5 580M Dual Core processor, 2.66-GHz, (SC turbo up to 3.33-GHz), 3-MB L3 cache
625826-001 Intel Core i7 640M Dual Core processor, 2.80Hz (SC turbo up to 3.33-GHz), 4-MB L3 cache
626039-001 Intel Core i5 460M Dual Core processor, 2.53-GHz, 3-MB L3 cache
630284-001 Display cable kit for models equipped with WWAN
630713-001 System board for use in models equipped with 512 MB of HD6370 discrete graphics memory
630714-001 System board for use in models equipped with 1 GB of HD6370 discrete graphics memory
633863-001 System board for use in models equipped with WiMAX and UMA graphics
634336-001 Thermal pad kit
634693-001 Intel Core i5 480M Dual Core processor, 2.66-GHz, 3-MB L3 cache
636631-001 9-cell, 100-WH (3.0-Ah) Li-ion battery
663545-001 Speaker, 8 ohm
672516-001 Hard drive mounting hardware
678100-001 320-GB, 7200 RPM hard drive
678101-001 500-GB, 7200 RPM hard drive
678102-001 640-GB, 7200 RPM hard drive
678103-001 750-GB, 7200 RPM hard drive
34 Chapter 3 Illustrated parts catalog

HP Pavilion dm4 Specifications

General

Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-400 Series
Processor socket	BGA 1288
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.26 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.53 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	17
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® HM55 Express
Memory slots	2x SO-DIMM
Internal memory	3 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 1 + 1 x 2 GB
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD, xD
Number of HDDs installed	1
Display diagonal	14 \
Display brightness	200 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Contrast ratio (typical)	500:1
Display response rise/fall	8 ms
Type	PC
LightScribe	-
Disc types supported	CD-R, CD-ROM, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RAM, DVD-ROM, DVD-RW
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz
Speakers manufacturer	Altec Lansing
Video capturing speed	24 fps
Front camera resolution	640 x 480 pixels
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet, WLAN
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 7 Home Premium
Form factor	Clamshell
Product type	Laptop
Country of origin	China
Battery life (max)	- h
Number of battery cells	6
AC adapter power	65 W
Cable lock slot type	Kensington
Processor code	SLBPM
Processor ARK ID	43537
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1, SSE4.2
Intel® Turbo Boost Technology	1.0
Operating altitude	-15 - 3048 m
Non-operating altitude	-15 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	228 mm
Width	340.8 mm
Weight	1990 g
Height (rear)	32.2 mm
Height (front)	25 mm
Depth (imperial)	8.98 \
Width (imperial)	13.7 \
Height (rear) (imperial)	1.26 \
Height (front) (imperial)	0.98 \
