5–2 Maintenance and Service Guide
Removal and Replacement Procedures
5.2 Disassembly Sequence Chart
Use the chart below to determine the section number to be
referenced when removing computer components.
Disassembly Sequence Chart
Section Description
# of Screws Removed
5.3 Preparing the Computer for
Disassembly
Battery pack 0
5.4 Hard Drive 2 loosened to remove the
hard drive cover
2 to remove the hard drive
4 to disassemble the
hard drive
5.5 Computer Feet 0
5.6 Memory Module 2 loosened to remove the
memory/Mini PCI module
compartment cover
2 loosened to release the
memory shield
5.7 Mini PCI Communications
Module
0
Å
To prevent an unresponsive system and the display of a
warning message, install only a Mini PCI device authorized
for use in your computer by the governmental agency that
regulates wireless devices in your country. If you install a
device and then receive a warning message, remove the
device to restore computer functionality. Then contact
Customer Care.
5.8 RTC Battery 0
