Page #148 background imageLoading...
Page #148 background image
Creating recovery discs
NOTE: HP recommends that you create recovery discs to be sure that you can restore your system
to its original factory state if you experience serious system failure or instability. Create these discs after
setting up the computer for the first time.
NOTE: Handle these discs carefully and keep them in a safe place. The software allows the creation
of only one set of recovery discs.
NOTE: If your computer does not include an internal optical drive, you can use an optional external
optical drive (purchased separately) to create recovery discs, or you can purchase the recovery discs
for your computer from the HP Web site.
Note the following guidelines before creating recovery discs:
You will need high-quality DVD-R, double-layer DVD-R, DVD+R, double-layer DVD+R, BD-R
(writable Blu-ray), or CD-R discs. All these discs are purchased separately. DVDs and BDs have
a much higher capacity than CDs. If you use CDs, up to 20 discs may be required, whereas only
a few DVDs or BDs are required.
NOTE: Read-write discs, such as CD-RW, DVD±RW, double-layer DVD±RW, and BD-RE
(rewritable Blu-ray) discs, are not compatible with the Recovery Manager software.
The computer must be connected to AC power during this process.
Only one set of recovery discs can be created per computer.
Number each disc before inserting it into the optical drive.
If necessary, you can exit the program before you have finished creating the recovery discs. The
next time you open Recovery Manager, you will be prompted to continue the disc creation process.
To create a set of recovery discs:
1. Select Start > All Programs > Recovery Manager > Recovery Manager.
Recovery Manager opens.
2. Click Advanced Options.
NOTE: If you are operating the computer on battery power, you will be prompted to connect to
AC power before you can go to the next step.
3. Click Recovery disc creation, and then click Next.
4. Follow the on-screen instructions.
140 Chapter 8 Backup and Recovery

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Pavilion dv6 and is the answer not in the manual?

HP Pavilion dv6 Specifications

General IconGeneral
LED backlightYes
Display surfaceGloss
Display diagonal15.6 \
Display brightness200 cd/m²
Display resolution1366 x 768 pixels
Native aspect ratio16:9
Bus typeDMI
SteppingD2
Tjunction100 °C
Processor cache6 MB
Processor cores4
Processor modeli7-2670QM
System bus rate5 GT/s
Processor familyIntel® Core™ i7
Processor seriesIntel Core i7-2600 Mobile Series
Processor socketBGA 1224
Processor threads8
Processor codenameSandy Bridge
Processor frequency2.2 GHz
Processor cache typeL3
Processor lithography32 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor boost frequency3.1 GHz
Processor operating modes64-bit
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)45 W
CPU multiplier (bus/core ratio)22
Maximum number of PCI Express lanes16
Motherboard chipsetIntel® HM65 Express
Memory slots2x SO-DIMM
Internal memory8 GB
Internal memory typeDDR3-SDRAM
Memory layout (slots x size)2 x 4 GB
HDD size2.5 \
HDD speed5400 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi DL
Total storage capacity500 GB
Compatible memory cardsMMC, SD
Number of HDDs installed1
On-board graphics card ID0x116
Discrete graphics card modelAMD Radeon HD 7690M XT
On-board graphics card modelIntel® HD Graphics 3000
Discrete graphics card memory2 GB
Discrete graphics memory typeGDDR5
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1200 MHz
Audio systemBeats Audio
Number of built-in speakers2
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Charging port typeDC-in jack
HDMI ports quantity-
Headphone connectivity3.5 mm
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 2.0 ports quantity0
Pointing deviceTouchpad
Operating system installedWindows 7 Home Premium
Form factorClamshell
Product typeLaptop
Product colorSilver
Country of originChina
Processor codeSR02S
Processor ARK ID53470
Processor package size31 mm
Supported instruction setsAVX
Intel Identity Protection Technology version1.00
Battery life (max)- h
Number of battery cells6
AC adapter power120 W
Operating altitude-15 - 3048 m
Non-operating altitude-15 - 12192 m
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth246.8 mm
Width378 mm
Height35.2 mm
Weight2910 g
