Speakers
Table 6-9 Speaker description and part number
Description Spare part number
Speakers L72708-001
Before removing the speakers, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 27).
2. Remove the bottom cover (see Bottom cover on page 28).
3. Disconnect the battery (see Battery on page 37).
4. Remove the fans (see Fans on page 41).
5. Remove the system board (see System board on page 45).
Remove the speakers:
1. Remove the two broadhead Phillips M2.0 × 2.0 screws (1) that secure the speakers to the computer.
2. Remove the speakers from the computer (2).
Reverse this procedure to install the speakers.
48 Chapter 6 Removal and replacement procedures for authorized service provider parts
