HP Photosmart M527 User Manual

Set the region
Along with the Language setting, the Region setting
determines the default date format and the format of the
video signal for displaying camera images on a
television when connected through an optional
HP Photosmart Premium camera dock or wireless dock
base (see Using the Setup Menu on page 31).
Use
to choose the region you want, then press
.
Set the date and time
1.
Use
to adjust the highlighted value.
2. Use
to move to the other selections and repeat
Step 1 until the date and time are set correctly.
3.
Press
when the date, time, and format settings
are correct, then press
again to confirm.
To change the date and time later, use the Setup
Menu (see Using the Setup Menu on page 31).
Install and format an optional memory card
1. Turn off the camera and
open the Battery/Memory
card door.
2. Insert the optional memory
card in the small slot as
shown. Make sure the
memory card snaps into
place.
3. Close the Battery/Memory
card door and turn on the
camera.
Always format memory cards
before first use.
1.
With the camera turned on, press
until appears briefly in the upper right
corner of the Image Display. This indicates you are in Playback.
2.
Press
.
3.
Use
to select Format Card, then press .
4.
Use
to select Yes, then press to format the card.
Note Once you install a memory card, all new images and video clips are stored
on the card, rather than in internal memory. To use internal memory and view
images stored there, remove the memory card. To transfer images from internal
memory to an optional memory card, see Move Images to Card under Using the
Design Gallery Menu on page 22.
For information about supported memory cards, see Storage on page 42.
Chapter 1
8

HP Photosmart M527 Specifications

General

I/O ports	1x USB 1x Dock
Display diagonal	2 \
Display resolution (numeric)	480 pixels
Memory slots	-
Memory upgrade	4 GB
Internal memory	16 MB
Storage media capacity	16 MB internal memory, capacity: up to 6 photos (accepts SD cards up to 1 GB capacity)
Compatible memory cards	sd
Maximum memory card size	2 GB
Storage temperature (T-T)	-30 - 65 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	15 - 90 %
Operating relative humidity (H-H)	15 - 85 %
Safety	Canada [Canadian Approval (CSA, cUL or equivalent)], EEA [one European Safety Agency mark (TUV, BSI, NEMKO), CE Certificate of Conformity], US [NRTL (UL, CSA, NRTL or equivalent)], Croatia (ZIK), Czech Republic (EZU), Estonia/Lithuania (Certificates), Hungary (MEEI), Mexico (NOM), Poland (PCBC), Russia (GOST), Slovakia (EVPU), South Africa (Certificate), Slovenia (SQI)
Metering	TTL
Interface	USB 2.0
Photo mode	Auto, Action, Beach and Snow, Burst, Fast Shot, Landscape, Macro, Night portrait, Portrait, Self Timer, Sunset
Color depth	36 bit
Minimum RAM	64 MB
Picture mode	Auto (default), Action, Beach and Snow, Burst, Fast Shot, Landscape, Macro, Night portrait, Portrait, Self Timer, Sunset
Size (imperial)	3.74 \
Power management	Universal AC adapter: 100 to 240 VAC (50/60 Hz) input; 5 VDC, 2000 mA output
Video capability	Yes
Minimum processor	Pentium II 233 MHz
Dimensions (WxDxH)	95 x 31.7 x 62 mm
Export file formats	JPEG (EXIF 2.2) for still images with embedded audio, MPEG 1 for video clips
Camera shutter speed	2 - 1/1000 s
Video memory capacity	Maximum length is limited to the size of the memory card or internal memory.
Package weight (imperial)	0.89 lbs
Minimum storage drive space	400 MB
Minimum system requirements	CD-ROM drive Internet Explorer 5.01
Compatible operating systems	Windows 98/98SE/2000/Me/XP Mac OS X v 10.2.8, 10.3, 10.5
Package dimensions (W x D x H)	7.2 x 6.4 x 1.9 \
Focal length (35mm film equivalent)	38 - 105 mm
Minimum system requirements for Macintosh	Mac OS X v 10.2.8, 10.3, 10.4; 128 MB RAM, 250 MB available hard disk space, built-in USB
Bundled software	HP Photosmart Premier
White balance	fluorescent, manual, shade, tungsten
Self-timer delay	10 s
Processor frequency	2330 MHz
Megapixel	6.3 MP
Sensor type	CCD
Image sensor size	1/2.5 \
Package weight	520 g
ISO sensitivity	100, 200, 400, Auto
Motion JPEG frame rate	20 fps
Maximum video resolution	320 x 240 pixels
Battery technology	Alkaline
Power requirements	2 AA batteries (Photo Lithium, rechargeable NiMH) Universal AC power adapter: 100 to 240 VAC (50/60 Hz) input; 5 VDC, 2000 mA output
Number of batteries supported	2
Product color	Silver
Quantity per pallet	720 pc(s)
Number of layers per pallet	6 pc(s)
Number of cartons per pallet	30 pc(s)
Case or master carton quantity	4 pc(s)
Flash modes	Auto, Red-eye reduction

Weight and Dimensions

Depth	31.7 mm
Width	95 mm
Height	62 mm
Weight	140 g
Weight (imperial)	Without batteries 0.3 lb lbs
Pallet dimensions (W x D x H)	1016 x 1219 x 1218 mm
Maximum dimensions (W x D x H)	97 x 36 x 63 mm
Pallet dimensions (W x D x H) (imperial)	40 x 48 x 48 \
Case or master carton dimensions (W x D x H)	7.8 x 7.6 x 7 mm
