Volume and power button board
Description Spare part number
Volume and power button board 795935-001
Before removing the volume and power button board, follow these steps:
1. Turn off the tablet. If you are unsure whether the tablet is off, turn the tablet on, and then shut it down
through the operating system.
2. Disconnect the power from the tablet by unplugging the power adapter cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see
Back cover on page 14).
5. Remove the battery (see
Battery on page 15).
6. Remove the rear-facing webcamera (see
Rear-facing webcamera on page 16).
7. Remove the front-facing webcamera (see
Front-facing webcamera on page 17).
▲
Remove the volume and power button board:
Reverse this procedure to install the volume and power button board.
Speakers
Description Spare part number
Top Speaker Kit (includes speaker and cables) 795933-001
Bottom Speaker Kit (includes speaker and cables) 795927-001
Before removing the speakers, follow these steps:
Volume and power button board 19
