8. Lift the keyboard connector latch (2), and then disconnect the keyboard cable from the system
board (3).
9. Remove the keyboard.
Reverse this procedure to install the keyboard.
Bottom cover
Description Spare part number
For use in 6460b models:
Includes a 2-button touchpad and fingerprint reader 642741-001
Includes a 2-button touchpad without a fingerprint reader 642742-001
Includes a 4-button touchpad with a fingerprint reader 642743-001
Includes a 4-button touchpad without a fingerprint reader 642746-001
For use in 8460p models:
Includes a 4-button touchpad with a fingerprint reader 642744-001
Includes a 4-button touchpad without a fingerprint reader 642747-001
For use in 8460w models:
Includes a 4-button touchpad with a fingerprint reader 642745-001
98 Chapter 4 Removal and replacement procedures
