HP ProCurve 5412ZL Planning And Implementation Guide

2-23
Operating Rules
Provisioning Power for PoE
Operating Rules
HP ProCurve Switch xl PoE Module for the 5300xl
Switch
For the HP ProCurve Switch xl PoE Module to function it must be installed in
an HP ProCurve Switch 5300xl. The module will receive it’s operational power
from the switch and its PoE power from the 600 RPS/EPS or an 610 EPS.
Table 2-11. Maximum Power Allocations
PoE Devices Internal Only Internal and EPS EPS Only
HP ProCurve Switch xl
PoE Module
No internal PoE power. No internal PoE power.
(See EPS only.)
408/204* watts available to
ports 1-24 on the module.
* If both EPS ports on the 600 RPS/EPS or both ports of a pair on the 610 EPS are connected to modules, each module
can receive 204 watts of power. If a single module is connected to the EPS ports, that module can receive 408 watts.
