HP 460W Common Slot Gold Hot Plug Power Supply Kit
Part Number
503296-B21
Input Voltage Range (Vrms) 100 to 240
Frequency Range (Nominal) (Hz) 50/60
Nominal Input Voltage (Vrms) 100 120 208 200 220 230 240
Maximum Rated Output Wattage 460 460 460 460 460 460 460
Nominal Input Current (A rms) 5.5 4.5 2.6 2.5 2.4 2.3 2.2
Max Rated Input Wattage Rating
(Watts)
526 520 505 505 503 503 503
Max. Rated VA (Volt-Amp) 548 542 527 527 524 524 524
Efficiency (%) at Max. Rated Output
Wattage
87.5 88.5 91 91 91.5 91.5 91.5
Power Factor 0.97 0.97 0.97 0.97 0.97 0.97 0.97
Leakage Current (mA) 0.42 0.50 0.83 0.87 0.92 0.96 1.00
Max. Inrush Current (A peak) 30 30 30 30 30 30 30
Max. Inrush Current duration (mS) 20 20 20 20 20 20 20
Maximum British Thermal Unit
Rating (BTU-Hr)
1794 1773 1725 1725 1715 1715 1715
HP 750W Common Slot Gold Hot Plug Power Supply Kit
Part Number
512327-B21
Input Voltage Range (Vrms) 100 to 240
Frequency Range (Nominal) (Hz) 50/60
Nominal Input Voltage (Vrms) 100 120 208 200 220 230 240
Maximum Rated Output Wattage 750 750 750 750 750 750 750
Nominal Input Current (A rms) 8.9 7.4 4.3 4.1 3.9 3.7 3.6
Max Rated Input Wattage Rating
(Watts)
857 847 824 825 820 820 820
Max. Rated VA (Volt-Amp) 894 884 859 859 854 854 854
Efficiency (%) at Max. Rated Output
Wattage
87.5 88.5 91 91 91.5 91.5 91.5
Power Factor 0.97 0.97 0.97 0.97 0.97 0.97 0.97
Leakage Current (mA) 0.42 0.50 0.83 0.87 0.92 0.96 1.00
Max. Inrush Current (A peak) 30 30 30 30 30 30 30
Max. Inrush Current duration (mS) 20 20 20 20 20 20 20
Maximum British Thermal Unit
Rating (BTU-Hr)
2925 2892 2812 2812 2797 2797 2797
QuickSpecs
HP ProLiant DL180 Generation 6 (G6)
Power Specifications
DA - 13248 North America — Version 53 — September 24, 2012 Page 50

HP ProLiant DL180 Generation 6 (G6) Specifications

General

Storage	Up to 12 LFF or 25 SFF drives
Form Factor	2U Rack
Chipset	Intel 5520 Chipset
Processor	Intel Xeon 5500 and 5600 series
Network	Embedded NC382i Dual Port Gigabit Ethernet
Power Supply	Dual 460W or 750W hot-plug power supplies
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
RAID	Integrated HP Smart Array P410 Controller (RAID 0/1/1+0/5) with optional battery-backed write cache (BBWC) or Flash-Backed Write Cache (FBWC). Optional HP Smart Array P212 Controller (RAID 0/1/1+0)
