HP 1200W 12V Hot Plug AC Power Supply
HP 1200W 12V Hot Plug AC Power SupplyHP 1200W 12V Hot Plug AC Power Supply
HP 1200W 12V Hot Plug AC Power Supply
Part Number
437572-B21
Input Voltage Range ( V rms )
100 to 240
Frequency Range (Nominal) ( Hz )
50/60
Nominal Input Voltage ( Vrms )
100
100100
100 120
120120
120 200
200200
200 208
208208
208 220
220220
220 230
230230
230 240
240240
240
Maximum Rated Output Wattage Rating
800 900
1200 1200 1200 1200 1200
Nominal Input Current ( A rms )
9.7 9.0 7.0 6.8 6.4 6.1 5.9
Maximum Rated Input Wattage Rating ( Watts )
930
1034 1348 1348 1348 1348 1348
Maximum Rated VA ( Volt-Amp )
970
1079 1406 1406 1406 1406 1406
Efficiency ( % )
86 87 89 89 89 89 89
Power Factor
0.97
Leakage Current ( mA )
0.42 0.50 0.83 0.87 0.92 0.96 1.00
Maximum Inrush Current ( A peak )
30
Maximum Inrush Current duration ( mS )
20
Maximum British Thermal Unit Rating ( BTU-Hr )
3174 3530 4600 4600 4600 4600 4600
HP 1200W -48V DC Common Slot Power Supply
HP 1200W -48V DC Common Slot Power SupplyHP 1200W -48V DC Common Slot Power Supply
HP 1200W -48V DC Common Slot Power Supply
Part Number
437573-B21
Input Voltage Range ( V rms )
36-72
Frequency Range (Nominal) ( Hz )
DC
Nominal Input Voltage ( Vrms )
36
3636
36 48
4848
48 72
7272
72
Maximum Rated Output Wattage Rating
1200 1200 1200
Nominal Input Current ( A rms )
38 28 19
Maximum Rated Input Wattage Rating ( Watts )
1380 1350 1365
Maximum Rated VA ( Volt-Amp )
1380 1350 1365
Efficiency ( % )
87 89 88
Power Factor
N/A
Leakage Current ( mA )
N/A
Maximum Inrush Current ( A peak )
20 25 35
Maximum Inrush Current duration ( mS )
1 1 3
Maximum British Thermal Unit Rating ( BTU-Hr )
4713 4610 4662
QuickSpecs
HP ProLiant DL580 Generation 5 (G5)
HP ProLiant DL580 Generation 5 (G5)HP ProLiant DL580 Generation 5 (G5)
HP ProLiant DL580 Generation 5 (G5)
Power Specifications
DA - 12770 Worldwide — Version 44 — November 23, 2010
Page 49
