2. Remove the front-facing webcamera (2) and cable.
Reverse this procedure to install the front-facing webcamera.
Rear-facing webcamera
Description Spare part number
Rear-facing webcamera (includes cable) 743874-001
Before removing the rear-facing webcamera, follow these steps:
1. Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the tablet cover (see
Tablet cover on page 12).
5. Disconnect the battery cable from the system board (see
Battery on page 15).
Remove the rear-facing webcamera:
1. Release the ZIF connector (1) to which the rear-facing webcamera cable is attached, and then
disconnect the rear-facing webcamera cable from the system board.
Removal and replacement procedures
17
