HP t410 User Manual

Power-On Sequence
At power-on, the flash boot block code initializes the hardware to a known state, then performs basic
power-on diagnostic tests to determine the integrity of the hardware. Initialization performs the
following functions:
1. Initializes CPU and memory controller.
2. Initializes and configures all PCI devices.
3. Initializes USB devices to a known state.
4. The unit boots the operating system.
Beep Codes
uBoot provides some feedback during startup according to the following table. If the system cannot
start up due to a catastrophic error (such as no RAM), no beep sounds; return the unit for service. If
the system can start up but encounters some other catastrophic error (such as the eMMC is
unreadable), 3 beeps are played; return the unit for service. In normal operation, 1 beep should
sound. If the system encounters a recoverable error such as the eMMC flash is corrupted, 2 beeps
sound to indicate the user should reflash the unit.
Number of Beeps Action
0 Return for service.
1 Normal operation.
2 Reflash the unit.
3 Return for service.
Power-On Sequence 5

HP t410 Specifications

General

Processor cores	1
Processor model	Cortex A8
Processor family	Texas Instruments ARM
Motherboard chipset	-
Processor frequency	1 GHz
Storage media	Flash
Card reader integrated	No
Total storage capacity	2 GB
Internal memory	1 GB
Internal memory type	DDR3-SDRAM
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
USB 2.0 ports quantity	4
VGA (D-Sub) ports quantity	0
Operating system installed	Smart Zero
Power supply	24 W
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Product color	Black
Country of origin	China

Weight and Dimensions

Depth	185 mm
Width	148 mm
Height	32 mm
Weight	638 g

Summary

Product Description

Product features

Lists common features of HP thin clients and specific features of the t410 Smart Zero Client.

Serial Number Location

Details the location of the unique serial number on the thin client for customer service.

Front Panel Components

Identifies and describes the components located on the front panel of the HP t410 Smart Zero Client.

Rear Panel Components

Identifies and describes the components located on the rear panel of the HP t410 Smart Zero Client.

Diagnostics and Troubleshooting

LEDS

Explains the function and status of Power and IDE Flash Activity LEDs on the thin client.

Power-On Sequence

Describes the hardware initialization and diagnostic tests performed during the client's power-on sequence.

Beep Codes

Lists and explains the beep codes emitted by the uBoot system during startup for error indication.

Basic Troubleshooting

Provides initial steps and checks for common operating problems or failure to power on.

Troubleshooting Flowcharts

Presents visual guides to diagnose and resolve specific operational issues with the thin client.

Modifying Client Settings

Tree View

Explains how to display and navigate the client's registry settings using the Profile Editor's tree view.

Changing Settings

Details the process for modifying client settings, using record volume as an example.

Restoring a Corrupt uBoot

Outlines the procedure for handling a corrupt uBoot, indicating the unit must be sent for repair.

Specifications

Electrostatic Discharge

Preventing Electrostatic Damage

Lists precautions to prevent damage to sensitive components from electrostatic discharge during handling.

Grounding Methods

Describes various methods for grounding the thin client to prevent electrostatic damage.
