Connector repair
This procedure includes Displ
ayPort and HDMI connectors.
The connectors are on the m
ain board (board part number CBPC2EBH7Q1
).
The connectors
identifiers are as follows:
Befor
e
r
epairi
ng
connectors,
follow
these
steps:
▲
Prepare the
monitor for
disassembly. See
Preparation for
disassembly
on
page 13.
Connector
Location
DisplayPort
CN501
HDMI
CN502
CN
501
Main Board
CN
502
18
20
