19" LCD Color Monitor HP VS19E
14
6.3 Electrical Block Diagram
6.3.1 Scalar Board
Scalar IC GM2621-LF-BC (Include ADC, OSD, MCU)
(U301)
EEPROM
AT24C16AN
(U304)
EEPROM
M24C02
(U304)
H sync
V sync
RGB
DDC_CLK,
DDC_DAT
LCD Interface
(
CN501
)
D-Sub
Connector
(CN202)
Crystal
14.31818MHz
(X301)
Key Board
Control
(CN602)
