4.6 Abnormal plug and play operation
Confirm the host computer supplies DDC/CI mode.
OK
NG
Failure Point
The host machine is not communicated in DDC/CI
mode.
Check the voltage on I304 pin 8 that is DC 5 V.
OK
NG
Failure Point
1) Printed wire broke between I304 pinv8, D307 and
P302 pin 9.
2) D307 is failure.
Check the output signal of I2C data / clk on I304 pin 5,
6.
OK
NG
Failure Point
I304 is failure.
Check the voltage on P302 pin 9 that is DC 5 V.
OK
NG
Failure Point
TheVGAvideocableisfailure.
Check the signals if is high level on P302 pin 12, 15
that is I2C data / clk signal.
OK
NG
Failure Point
TheVGAvideocableisfailure.
Failure Point
1) Printed wire broke between I306 pin 65, 64, I304 pin
5, 6 and P302 pin 12, 15.
2) I306 maybe failure.
3) R328, R329 is open.
4) C331, C332, R326, R327 is short.
4.6.1 Abnormal plug and play operation for VGA
Page 18
