HP W1907& WF1907 Service Manual
1. Power Board Operation Theory
1.1
Line
filter
consists
of
C801,
T801,
C802,
C803,
C804,
C808,
C809,
C815,
C819,
C820,
C825.
It
eliminates
high
frequency interference
to
meet
EMI’s
requirement.
1.2
Rec
&
Filter
Bridge
diode
D812,
D813,
D814,
D815
converts
AC
source
into
pulsed
DC.
This
pulsed
DC
is
smoothed
and filtered
by
C805.
R802
is
an
NTC
(negative
thermal
coefficient
)
resistor,
used
to
reduce
inrush
current
to
be within
safe
range.
1.3
Power
transformer
:
T802
converts
energy
for
square
wave
from
power
source
C805
to
secondary
side
to
generate
+5V,
+12V
and +22V.
1.4
Output
:
The
square
wave
from
T802
is
rectified
by
D808
D809,
D810,
then
filtered
by
C817,
C818,
C824,
C823,
C830,
C833, C822
to
generate
+22.5V
and
+12V,
+5V
respectively.
1.5
Driver
:
Q803
drive
T802
from
PWM
control
of
I801
for
power
converted.
1.6
FB
:
Negative
feedback
CKT
consists
of
coupler
I802
and
adjustable
regulator
I803.
It
can
maintain
output voltages
+22.5V
and
+12V,
+5V
at
a
stable
level.
1.7
PWM
:
1.7.1
Start
:
When
power
is
turned
on.
C807
is
charged
a
11V
and
a
starting
current
above
40uA
to
pin
1
of
I801. I801
starts
to
oscillate
and
outputs
a
pulse
train
through
pin
6
to
drive
Q803.
1.7.2
OPP
:
When
Q803
turns
on,
C805
supplies
a
linearly
increasing
triangle
current
through
the
primary
inductance
of
T802
to
the
driver
Q803,
once
the
peak
value
of
this
current
multiplied
by
R811
exceeds
0.52V,
pulse train
will
be
turn
off
immediately
to
protect
Q803,
T802
from
being
burned
out.
1.7.3
Regulation
:
If
output
voltage
+22V
goes
up,
the
R
terminal
of
I803
gets
more
bias,
accordingly
photo transistor
and
diode
flows
more
current.
The
voltage
of
pin
2
goes
up
too,
making
the
pulse
width
of pin
6
to
become
narrower.
So
the
output
voltage
+22V
will
be
pulled
down
to
a
stable
value.
1.7.4
OVP
:
If
+22.5V
goes
up
too
much,
the
induced
voltage
on
pin
4
of
T802
becomes
large
also.
Suppose
that
it is
over
20V.
The
pulse
train
at
pin
6
goes
down
to
zero,
shutting
Q803
off
immediately.
1.7.5 SCP
:
If
output
terminal
is
short
to
ground,
transistor
does
not
conduct,
hence
I802
does
not
conduct either.
Then
oscillation
of
I801
is
stop,
shutting
Q803
off
immediately.
